Camjoy Electronic Endoscope / HD101
Camjoy HD101 Disposable Hysteroscope
Disposable hysteroscope with 2.2 mm working channel and HD USB output.
HD101 is a disposable hysteroscope configured for forward viewing, HD imaging and single-use workflow planning in gynecological endoscopy.
WorkflowGynecology / hysteroscopy
Image system1280×720
Model familyHD101
Product Highlights
HD imagingHD imaging with compatible main units
2.2 mm working channel2.2 mm working channel for 5FR/6FR instruments
Ergonomic lightweight designErgonomic lightweight design
16 deg elbow design16 deg elbow design for visible bilateral tubes
Actual Product Views
Review the product body, display connection and configuration details to match the model with the intended clinical workflow.
Physical Configuration Table
Supports forward-viewing hysteroscopy with a compact working-channel configuration.
| Product code | HD101 |
|---|---|
| Clinical workflow | Gynecology / hysteroscopy |
| Model options | Model: HD5522 |
| Outer diameter / blade options | 5.5 mm |
| Working channel | 2.2 mm |
| Image resolution | 1280×720 |
| Field of view | 140 deg |
| Depth of field | 3-100 mm |
| Direction of view | Forward viewing |
| Light source / output | USB |
| Configuration note | Supports forward-viewing hysteroscopy with a compact working-channel configuration. |
Technical Specifications
| Model | HD5522 |
|---|---|
| Insertion tube outer diameter | 5.5 mm |
| Working channel inner diameter | 2.2 mm |
| Resolution | 1280×720 |
| Output | USB |
| Field of view | 140 deg |
| Depth of field | 3-100 mm |
| Direction of view | Forward viewing |
Ordering Notes
Before quotation, confirm the intended procedure, model code, insertion or blade size, channel diameter, compatible display or processor, accessory list and local registration needs.
- Model code and procedure type
- Insertion size or blade size
- Working-channel diameter
- Display or processor compatibility
- Single-use sterile workflow
- Local registration and package requirements
Inquiry Support
Use the product inquiry module at the bottom of this page to send quotation requirements. Share the model code, procedure type and display or processor requirements so Camjoy can confirm the correct configuration.
