Camjoy LRS105C1 Laser Resectoscope Set
✔ 22.5Fr Reduced Trauma
✔ 2.9mm HD Endoscope
✔ Morcelloscope Compatible
Extreme Precision for Delicate Anatomies in Laser Surgery
As Holmium Laser Enucleation of the Prostate (HoLEP) and Thulium Laser Enucleation (ThuLEP) become the gold standard, providing these treatments to patients with narrow urethras or pediatric anatomies requires specialized instrumentation. The Camjoy LRS105C1 Laser Resectoscope System is an engineering marvel designed specifically to address these challenges.
By replacing the standard 4mm scope with an advanced 2.9mm HD optical system, we have successfully reduced the total continuous flow sheath diameter to an ultra-slim 22.5Fr. This dramatic reduction in profile minimizes urethral stretching and virtually eliminates the risk of strictures, all while providing a highly stable platform for guiding delicate laser fibers (1.0mm to 1.6mm).
To guarantee maximum surgeon comfort during complex, lengthy procedures, the LRS105C1 features a high-grade lightweight plastic working element. This passive mechanism offers exceptional ergonomic balance, significantly reducing wrist torque and fatigue compared to heavy all-metal assemblies.
Clinical Advantages
- ✔ 22.5Fr Ultra-Slim Profile: Essential for pediatric patients and managing severe strictures.
- ✔ 2.9mm Optics: Brilliant visualization scaled down for minimally invasive access.
- ✔ Dedicated Laser Delivery: Interchangeable adapters ensure pinpoint laser accuracy.
- ✔ Ultra-Light Ergonomics: Premium plastic working element minimizes wrist fatigue.
- ✔ HoLEP Synergy: Sheath seamlessly accommodates urological morcellators for immediate extraction.
Engineering Excellence & Technology
1. The 22.5Fr Pediatric & Stricture Advantage
Standard 26Fr systems are often too traumatic for narrow anatomies. The LRS105C1 utilizes an intelligently designed 22.5Fr Outer / 20.5Fr Inner sheath combination. This ultra-slim profile dramatically reduces mechanical friction and urethral stretching, significantly lowering post-operative stricture rates while maintaining effective continuous flow irrigation to keep the operative field clear.
2. High-Definition 2.9mm Optics
To achieve the 22.5Fr profile without sacrificing fluid dynamics, the system shifts to a specialized 2.9mm HD Endoscope (9302.30). Using advanced rod-lens technology, this 30-degree optic delivers crisp, bright, high-resolution imagery that rivals larger scopes, ensuring perfect visibility in confined spaces.
3. Precision Laser Fiber Adapters
The core of the LRS105C1 is its specialized fiber delivery system. The set includes a suite of Laser Fiber Adapters (F5010 to F5016) designed to securely hold fibers ranging from ϕ1.0mm to ϕ1.6mm. This prevents lateral deflection when the laser fires, ensuring the energy is delivered exactly where the surgeon intends along the surgical capsule.
4. Seamless Morcelloscope Integration
It is exceptionally rare for an ultra-slim system to support advanced laser therapies. The LRS105C1 22.5Fr outer sheath (S2218-5C) is precision-engineered to accommodate matched urological morcellators. After the adenoma is enucleated, the laser working element is removed, allowing the morcelloscope to be directly introduced for rapid tissue extraction.
🌟 6 Key System Highlights
22.5Fr Ultra-Slim
The 22.5Fr outer sheath drastically reduces mechanical trauma, making it perfect for pediatric or narrow urethras.
2.9mm HD Optics
Advanced 2.9mm rod-lens technology delivers exceptional clarity and brightness in a fraction of the standard footprint.
Laser Optimized
Replaces traditional electrodes with specialized fiber guides, tailored specifically for Holmium and Thulium laser therapies.
HoLEP Ready
Specifically designed to match with corresponding morcelloscopes, providing a seamless workflow for laser enucleation.
Lightweight Handle
High-durability plastic working element (W5003P) provides unmatched ergonomic balance and reduces hand torque.
Click-Lock Design
Rapid, rotational-free assembly ensures the 30° scope view perfectly aligns with the laser fiber tip at all times.
📊 Detailed Ordering Information (LRS105C1)
The LRS105C1 is a highly specialized system built around the 2.9mm optic and 22.5Fr profile for laser enucleation. Below is the exhaustive component list, featuring full compatibility for various laser fiber diameters.
| Model No. | Description | Specification & Details |
|---|---|---|
| I. Main Components (Optics, Handles & Sheaths) | ||
| 9302.30 | HD Endoscope (Red Ring) | 30° | Ø 2.9mm | 302mm Length | Universal Compatibility |
| W5003P | Working Element (Passive) | Laser Type | Plastic Handle | Click-Locked |
| S2218-5C | Outer Sheath with Obturator | 22.5Fr | 180mm Length |
| S2020-5C | Inner Sheath with Obturator | 20.5Fr | 200mm Length |
| S2200-5C | Inner Sheath Adaptor | Click-Locked connecting bridge |
| II. Laser Fiber Adapters (For precise fiber stabilization) | ||
| F5010 | Fiber Adapter | For Ø 1.0mm Laser Fibers |
| F5012 | Fiber Adapter | For Ø 1.2mm Laser Fibers |
| F5014 | Fiber Adapter | For Ø 1.4mm Laser Fibers |
| F5016 | Fiber Adapter | For Ø 1.6mm Laser Fibers |
| III. Accessories & Valves | ||
| A4311 / A4312 | In-flow / Out-flow Valve | Stainless Steel Luer Lock |
| A8304 | Irrigator Connector | Secure fluid line connection |
| A4305 / A4306 | Huffman / Ellik Irrigator | For manual tissue chip evacuation |
| A4303 | Sealed Cap | 10 pcs per pack |
| R3340 | Cleaning Rod | Ø 3mm | 340mm Length |
| IV. Fistula Instruments (Complete Set) | ||
| F1695 – F2495 | Fistula Instruments | 16Fr, 18Fr, 20Fr, 22Fr, 24Fr (All 95mm Length) |
